Frame: 100% 4130 chromoly DJ frame, 3/8" Dropout, Threaded 73mm BB, Disc Mount
Fork: Manitou Circus Expert, 100mm, 20mm Thru-Axle
Handlebar: 2" rise, 30" wide, 31.8mm bore, Aluminum
Stem: 50mm
Headset: FSA Orbit Sealed
Brake Lever: Hydraulic
Brakes: Hydraulic
Grips: Lock-on
Saddle: Odyssey Big Stitch, Pivotal
Seat Post: Pivotal 27.2mm
Seat Clamp: Fairdale 30mm
Cranks: 19mm 48-Spline, 170mm
Chainwheel: 28T
BB Parts: Euro
Pedals: Odyssey Twisted Pro PC
Rims: 26" 32H
Front Hub: Sealed 20mm Thru Axle
Rear Hub: Sealed Cassette, 3/8" Axle, Disc
Tires: Maxxis DTH 2.3"
Chain: KMC Z1eHX
Driver: 12T
Fork Travel: 100mm
Fork Axle to Crown: 482mm
Fork Offset: 40mm
Top Tube (Effective): 625mm
Seat Tube (BB Center to TT Center): 340mm
Seat Tube Angle: 72°
Head Tube Length: 120mm
Head Tube Angle: 69.5°
Chain Stay Length: 379-389mm
Standover: 690mm
Stack: 570mm
Reach: 440mm
BB Drop: 20mm
Rear Dropout Spacing: 10x135mm
BB Type: 73mm threaded
Seat Post: 27.2mm
Seat Clamp: 30mm
Rear Tire Clearance: 2.3"
Wheel Size: 26"
